Alarko Diamond MC 750 E Series Submersible Pump for Gray Water and Rain Water
Portable submersible pump for clean, lightly polluted, and rainwater.
Portable submersible pump for clean, lightly polluted, and rainwater. For the discharge of gray water, rainwater reuse or drainage applications. In pool and garden applications
Application Areas
Portable submersible pump for clean, lightly polluted, and rainwater. For the discharge of gray water, rainwater reuse or drainage applications. In pool and garden applications
Reliable & Efficient
at a flow rate of 0.5 - 13.5 m3/h. Pump head of 0 to 8 meters. Very lightweight: 4.45 kg. Compact: Height 32.6 cm / Diameter 17.85 cm
Superior Pump Features
Discharge valve, pump casing and top cover are in PPO. Fan is made of NORYL. Graphite / Ceramic mechanical seal. Replaceable external suction box. (Provided free of charge with the product.)
Outstanding Features of Motor
1x230 V, 50 Hz. Current: 5.2 A. Power: 0.75 kW. Asynchronous, bipolar, winding type. IP 68 protection. F-grade isolation. Available for continuous operation. With floaters. Depth of Submersion: Max 10 meters
A closer look
Documents
Brochures, user manuals and technical documents — official Alarko Carrier PDFs.
