Alarko Diamond MI 550 SW Series Submersible Pump for Gray Water and Rain Water
Portable, floating type submersible pump for clean and lightly polluted water.
Portable, floating type submersible pump for clean and lightly polluted water. For the discharge of pool water, rainwater reuse or drainage applications
Application Areas
Portable, floating type submersible pump for clean and lightly polluted water. For the discharge of pool water, rainwater reuse or drainage applications
Reliable & Efficient
at a flow rate of 0 - 11 m3/h. Pump head of 0 to 8.5 meters. Very lightweight: 5.05 kg. Compact: Height 31.3 cm / Diameter 19.1 cm
Superior Pump Features
Discharge valve, pump casing and top cover are in PPO. Fan is made of NORYL. Graphite / Ceramic mechanical seal. Motor housing and bottom legs are made of NORYL
Outstanding Features of Motor
1x230 V, 50 Hz. Current: 2.43 A. Power: 0.55 kW. Asynchronous, bipolar, winding type. IP 68 protection. F-grade isolation. Available for continuous operation. With Built-in Floater. Depth of Submersion: Max 10 meters
A closer look
Documents
Brochures, user manuals and technical documents — official Alarko Carrier PDFs.
